Double walled construction, Inner chamber made of Mild Steel / Stainless Steel 304 Q & exterior made of G.I. Sheets powder coated.

• UNIQUE FEATURES

  • Ergonomic Design
  • Easy to use
  • Negligible Maintenance
  • High Temperature Accuracy

• CONSTRUCTION

  • Double walled construction, Inner chamber made of Mild Steel / Stainless Steel 304 Q & exterior made of G.I. Sheets powder coated.
  • Gap between the walls is filled with special grade glass wool for proper insulation to avoid heat loss and thereby saving energy.
  • Inner door made of Acrylic to see through the chamber & external metal door is fully insulated with S. S. lock, hinges.
  • Air Ventilation is provided on the top of unit to remove hot gases / fumes.
  • Supplied with galvanized wire mesh shelves.

• TECHNICAL DATA

  Temp. Range	5°C above ambient to 60°C
  Temp. Accuracy	With Thermostat : ± 2°C or Digital : ± 0.5°C
  Temp. Control	Temperature Controlled by Thermostat
  Digital Temp.	Micro-processor based Auto Tune P.I.D Digital Temperature Controller with PT 100 sensor & Resolution 0.1°C . Dual display one for process value (PV) & the other for Set Value of temperature
  Power Supply	230 Volts A.C 50 Hz Single phase.

• HEATING ELEMENT

  • Heating is by specially designed heaters made of special grade Nichrome wire (ISI Approved) which is fitted at the bottom of the oven

• OPTIONAL ACCESSORIES

  • Digital Temperature Controller - Micro-processor based Auto Tune P.I.D Digital Temperature Controller with PT 100 sensor & Resolution 0.1°C . Dual display one for process value (PV) & the another for Set Value of Temperature (SV)
  • Motorized Air circulation Blower for Universal Temperature
  • S.S Trays
  • Digital Temperature controller Cum Indicator with Timer.
  • Safety Thermostat.
